1.FEATURES - High temperature materials allow operation in ambient temperatures up to 180°C. - Soldered self-leaded construction for excellent solderability. - Very low DCR values and excellent current handling 2.APPLICATIONS - DC/DC converter, LNB(Set top box ,LED, Mobile) 3.SPECIFICATIONS Power Inductors for Power Circuits Image Series Part number L x W(mm) Height(MAX) Data sheet SPY Series SPY5022 5 X 5 2.5 SPM Series SPM3215 3 X 3 1.7 SPM3220 3 X 3 2.2 SPM4532 4.5 X 4 3.35 SPM6050 5.8 X 5.2 4.65 SPM8050 7.8 X 7 5.15 SPM10060 10 X 9 5.55 SPC Series SPC6025 6 X 6 2.5 SPC7030 7 X 7 3.0 SPC7040 7 X 7 4.0 SPC7060 7 X 7 6.0 SPC10040 10 X 10 4.0 SPC12060 12 X 12 6.0 SPC12080 12 X 12 8.0 Pass the AEC-Q200 Certification Test (SPE201610,3012 4020,5020 제외) SPE Series SPE201610H 2.01.6 1.0 SPE201610 2.11.7 1.05 SPE252012H 2.52.0 1.25 SPE252012 2.52.0 1.25 SPE3012 3 X 3 1.21 SPE3015 3 X 3 1.8 SPE4020 4 X 4 2.3 SPE4030 4 X 4 3.3 SPE5020 5 X 5 2.3 SPE5040 5 X 5 4.3 SPE6028 6 X 6 3.1 SPE6045 6 X 6 4.8 SPE8040 8 X 8 4.3 SPS Series SPS6028 6 X 6 2.8 SPS7032 7 X 7 3.2 SPS7045 7 X 7 4.5 SPS7060 7 X 7 6.0 SPS10050 10 x 10 5.2 SPS10050M 10 x 10 5.2 SPS12060 12 X 12 6.0 SPS12060M 12 X 12 6.0 SPS12080 12 X 12 8.0 SPS12080M 12 X 12 8.0 SPS15060M 15 X 15 6.0 SPS15080M 15 X 15 8.0 Pass the AEC-Q200 Certification Test (SPH8040,13050 제외) SPH Series SPH201610 2.6 X 1.6 1.0 SPH252010 2.5 X 2.0 1.0 SPH3020 3.4 X 3.2 2.0 SPH4020 4.6 X 4.2 2.0 SPH5030 5.5 X 5.2 3.0 SPH7030 7.1 X 6.6 3.0 SPH7040 7.1 X 6.6 4.0 SPH8040 8.8 X 8.2 3.8 SPH10040 11.5 X 10.3 4.0 SPH10050 11.5 X 10.3 5.0 SPH13040 13.8 X 12.6 4.0 SPH13050 13.8 X 12.6 5.0 SPH13060 13.8 X 12.6 6.0 SPH17070 17.15 X 17.15 7.0 Pass the AEC-Q200 Certification Test SPL Series SPL7045 7.3 X 7.3 4.5 SPL10080(Mn) 10.2 X 10.2 8.0 SPL10080(Mn)1 10.2 X 10.2 8.0 SPL12060 12.35 X 12.35 6.3 SPL120601 12.35 X 12.35 6.3 SPL12080(Ni) 12.35 X 12.35 8.3 SPL12080(Ni)1 12.35 X 12.35 8.3 SPL12080(Mn) 12.35 X 12.35 8.3 SPL12080(Mn)1 12.35 X 12.35 8.3
